Blue filter with thermal jacket

Jacketed thermal insulation basket filter is a new type of high efficiency filter equipment, made of stainless steel material;
It has the characteristics of strong corrosion resistance, good strength and long service life.

It is suitable for chemical, petroleum, pharmaceutical and other industrial fields.
The jacketed thermal insulation basket filter is mainly composed of a shell (or inner liner), a filter plate and a pressing mechanism.
(1) Shell:
Welded by steel plate, its thickness according to GB/T3041-1992 standard design and production; The shell surface should be smooth and smooth; The inner wall of the shell should be smooth and burr free.
(2) Inner liner:
Cylindrical container welded from carbon steel or stainless steel sheet (diameter of 400 ~ 600mm); The inner and outer walls are polished and chrome-plated; The bottom of the inner cavity is provided with water channels and drainage devices, in order to clean the internal dirt and impurities.
(3) Filter plate:
A porous mesh structure made of stainless steel wire; The thickness of the filter plate according to the use of different occasions to choose 0.2, 0.3 or 0.4mm specification size is appropriate (special conditions can be customized according to user needs), the filter plate and the clamping mechanism of the connection using special bolts fixed reliable; The edge of the filter plate should be smooth without edges and corners, so as not to damage the sealing surface and cause leakage.
(4) Pressing mechanism:
A mechanical device used to press the filter element on the shell and the filter element is in close contact with the shell without falling off; Generally using hydraulic transmission mode for operation control, when the pressure of the hydraulic system reaches the rated value, it automatically stops working and carries out the protection measures of oil drainage and pressure reduction. (Note) This product can also be configured according to customer needs to manually control the on-off valve operation.
(5) Inlet and outlet water pipe system.
(6) Electrical control system.
1. Check whether all parts are intact before installation.
2. Install valves in the pipeline system.
3. Open the water outlet cover.
4. Loosen the water inlet cover.
5 Insert the water inlet pipe.
6. Close the water outlet.
7. Turn on the power switch.
8, adjust to the proper position.
9. Power on.
10. Start working.
11. Observe regularly during operation.
12, cut off the power after the end of the operation.
13, clean up the site.
14. Clean and maintain.
15. Packing and warehousing.
16. Store in a dry and ventilated place.
